KATSU Tools 850W Submersible Water Pump Clean Dirty Float Switch Sump 151682

KATSU Tools 850W Stainless Steel Submersible Water Pump for Clean & Dirty Water 17500L/H IPX8 with Float Switch & 2" Outlet 151682

Product Overview

The KATSU Tools 850W Submersible Water Pump (SKU: 151682) is a heavy-duty, highly efficient drainage solution engineered with a durable stainless steel motor housing for clean and muddy wastewater transfer. Powered by an 850W motor, it produces a high maximum flow rate of up to 17,500 litres per hour (17.5 m³/h) with an impressive 10-metre head lift and a maximum submersion depth of up to 8 metres. Certified IPX8 waterproof and weighing just 6.8 kg, this pump easily passes solid particles up to 35mm in diameter without clogging. Equipped with an automatic float switch for dry-running protection and a G2" (2-inch) discharge outlet with reducers, it is ideal for irrigating gardens, as well as pumping contaminated water from wells, tanks, flooded cellars, basins, ponds, and pools.

Features

• Durable Stainless Steel Motor Casing: Constructed with a high-grade stainless steel motor housing for enhanced corrosion resistance and structural durability in wet environments.

• 850W High-Performance Motor: Delivers an impressive maximum flow rate of 17,500 L/h and a 10m max head for rapid evacuation of large water volumes from deep tanks, pits, and cellars.

• Handles Large Solid Particles up to 35mm: Designed to handle both clean water and contaminated or muddy wastewater containing abrasive particles up to 35mm in diameter.

• Automatic Float Switch Control: Integrated float switch automatically shuts off the motor when the water reaches a predetermined low level, effectively protecting the pump from dry running.

• IPX8 Waterproof Rating: Industrial-grade IPX8 waterproof rating ensures safe and reliable submersion up to 8 metres deep.

• 2" Outlet with Reducers: Outfitted with a G2" (2-inch) discharge connection supplied with reducers for flexible hose attachment.

• Lightweight & Portable: Weighing only 6.8 kg, making it easy to carry around garden ponds, yards, and flooded basins.

Technical Specifications

• Brand: KATSU Tools

• SKU: 151682

• Motor Power: 850 W

• Power Supply Voltage: 230 V ~ 50Hz

• Waterproof Rating: IPX8

• Maximum Flow Rate: 17,500 L/h (17.5 m³/h)

• Maximum Head Lift: 10 Metres

• Maximum Submersion Depth: 8 Metres

• Max. Solid Particle Diameter: 35 mm

• Discharge Outlet Size: G2" (2 Inch) with Reducers

• Net Weight: 6.8 kg

⚠️ Important Operational Notes & Safety Warnings

• ⚡ Cable Safety Warning: Never attempt to move, pull, or lift the pump using the electrical cable while operating or plugged in. Always move or lower the pump using a dedicated rope attached to the carrying handle.

• RCD Protection Recommended: It is strongly recommended to always connect the pump to a residual current device (RCD) leakage circuit breaker whenever electrical products are used near water.

• Permanent Installation Maintenance: In cases of permanent installation, check the starting mechanism (float switch or sensor) every 3 months to ensure proper operation, and regularly remove accumulated dirt/sediment from the sump.

• Operating Limitations & Prohibited Uses:

  • Do NOT pump water with a temperature exceeding 35 °C.

  • Do NOT use for continuous non-stop running applications (e.g., fountain pumps).

  • Do NOT use for drinking water supply or dishwashing machine water supply.

  • Do NOT pump corrosive, easily combustible, aggressive, or explosive liquids (such as gasoline, petroleum, or nitro thinner), saltwater, oils, or greases.

  • Avoid permanent submersion under 3 metres or more of water.
